I-Autoc KSQE480D50-I Three Phase Solid State Relay SSR 50A 480VAC, 4-32VDC Control
![i-autoc-ksqe480d50-i-50a-480vac-three-phase-solid-state-relay [1]](https://gomagcdn.ro/domains3/rezistentemag.ro/files/product/original/releu-static-ssr-i-autoc-ksn480d60-l-60a-480vac-comanda-3-32vdc-pentru-rezistente-electrice-copie-836878.jpeg "i-autoc-ksqe480d50-i-50a-480vac-three-phase-solid-state-relay [1]")
Delivery date: Your order is processed quickly. In-stock products are usually prepared and shipped the same day or the next day.
- Description
- Reviews (0)
The I-Autoc KSQE480D50-I is a three-phase solid state relay (SSR) designed for electronic switching of three-phase AC loads. It is particularly suitable for industrial electric heating, ovens, injection moulding machines, heating systems and automation panels.
According to the marking visible on the unit, the KSQE480D50-I is rated at 50A and 480VAC.
The power connections are clearly identified as L1, L2 and L3 on the supply side and U, V and W on the load side, allowing a three-phase electrical load to be controlled from a single SSR module.
Main features:
- Brand: I-Autoc
- Model: KSQE480D50-I
- Type: Solid State Relay / SSR
- Configuration: Three phase
- Rated current: 50A
- Load rating: 480VAC
- Electronic control
- Supply terminals: L1, L2, L3
- Load terminals: U, V, W
- LED indication
- No mechanical switching contacts
- Suitable for frequent switching
- Designed for industrial heating and automation applications
Typical applications include three-phase electric heaters, industrial ovens, mould heating, injection moulding machinery, tanks, air heaters, PID temperature control and industrial electrical panels.
A correctly sized SSR heatsink is required for high-current operation. The actual permissible continuous load must be determined according to cooling, ambient temperature and installation conditions.
